All New C-HR Specification

Transmisi / Transmission Type 7-Speed CVT 7-Speed CVT 7-Speed CVT 7-Speed CVT
Suspensi Depan / Front Suspension MacPherson strut MacPherson strut MacPherson strut MacPherson strut
Suspensi Belakang / Rear Suspension Double Wishbone Double Wishbone Double Wishbone Double Wishbone
Rem Depan / Front Brake Ventilated disc Ventilated disc Ventilated disc Ventilated disc
Rem Belakang / Rear Brake Solid Disc Solid Disc Solid Disc Solid Disc
Ukuran Ban / Tires Size 215/60 R17 96H 215/60 R17 96H 215/60 R17 96H 215/60 R17 96H
Sistem Kemudi / Steering System Power Assisted Rack & Pinion Power Assisted Rack & Pinion Power Assisted Rack & Pinion Power Assisted Rack & Pinion

Overall Panjang / Length (mm) 4,360 4,360 4,360 4,360
Overall Lebar / Width (mm) 1,795 1,795 1,795 1,795
Overall Tinggi / Height (mm) 1,565 1,565 1,565 1,565
Jarak Poros Roda / Wheelbase (mm) 2,640 2,640 2,640 2,640
Jarak Pijak Depan / Front Tread (mm) 1,550 1,550 1,550 1,550
Jarak Pijak Belakang / Rear Tread (mm) 1,570 1,570 1,570 1,570

Tipe Mesin / Engine Type 2ZR-FBE 2ZR-FBE 2ZR-FXE 2ZR-FXE
Isi Silinder / Displacement (cc) 1,798 1,798 1,798 1,798
Daya Maksimum / Maximum Output (ps/rpm) 140 / 6,000 140 / 6,000 98/5,200 98/5,200
Torsi Maksimum / Maximum Torque (kgm/rpm) 17.8 / 4,000 17.8 / 4,000 14.5/3,600 14.5/3,600
Bahan Bakar / Fuel Gasoline Gasoline Gasoline Gasoline
Kapasitas Tangki / Fuel Capacity (Liter) 50 50 43 43
Daya Maksimum / Maximum Power Electric Motor (ps) - - 72 72
Bore x Stroke (mm) 80.5 x 88.3 80.5 x 88.3 80.5 x 88.3 80.5 x 88.3
Sistem Bahan Bakar / Fuel System Fuel Injection Fuel Injection Fuel Injection Fuel Injection
Rasio Kompresi / Compression Ratio 10 : 1 10 : 1 13 : 1 13 : 1
Valve Mechanism 16-valve DOHC with VVT-i (intake) 16-valve DOHC with VVT-i (intake) 16-valve DOHC with VVT-i (intake) 16-valve DOHC with VVT-i (intake)
No of Cylinders & Arrangement (cc) 4 Cylinders 4 Cylinders 4 Cylinders 4 Cylinders
